Forged Couplings Manufacturer

At Steel Icon Stainless Pvt. Ltd., we are a leading manufacturer and global supplier of forged couplings, engineered to provide strong, leak-proof pipe connections in high-pressure systems. Our couplings are made using high-quality stainless steel and duplex alloys, designed to withstand high pressure, temperature, and corrosive environments.

We manufacture a full range of couplings as per ASTM, ASME, MSS, and DIN standards, widely used in oil & gas, chemical processing, power generation, marine, and utility systems.

What are Forged Couplings?

Forged couplings are short, cylindrical pipe fittings used to connect two pieces of pipe in a straight line. They are forged from solid steel blocks and machined to tight tolerances, ensuring durability and high-pressure integrity.

Available in full, half, and reducing types, forged couplings are offered in both socket weld and threaded ends to meet diverse industrial piping needs.

Products
Stainless Steel Bar
Fasteners
Forged Products
Flanges
Forged Fittings
Stainless Steel Billets
Round Corner Square Billets
Stainless Steel Pipes
Pipe Fittings
Valve

Specifications

Property	Specification
Material Grades	SS 304, SS 316, SS 321, SS 410, Duplex 2205
Size Range	½” to 4” (custom sizes available)
Types	Full Coupling, Half Coupling, Reducing Coupling
Connection Ends	Socket Weld, Threaded (NPT/BSP)
Pressure Ratings	Class 2000, 3000, 6000
Standards	ASTM A182, ASME B16.11, MSS-SP-95, DIN Standards

Equivalent Grades

Grade	UNS	EN / WNR
SS 304	S30400	1.4301 / X5CrNi18-10
SS 316	S31600	1.4401 / X5CrNiMo17-12-2
SS 321	S32100	1.4541 / X6CrNiTi18-10
SS 410	S41000	1.4006 / X12Cr13
Duplex 2205	S31803	1.4462 / X2CrNiMoN22-5-3

Chemical Composition

Element	SS 304	SS 316
Chromium (Cr)	18–20%	16–18%
Nickel (Ni)	8–10.5%	10–14%
Molybdenum (Mo)	–	2–3%
Carbon (C max)	0.08%	0.08%

Mechanical Properties

Property	SS 304 / SS 316
Tensile Strength (MPa)	515 – 750 MPa
Yield Strength (MPa)	205 – 310 MPa
Elongation (%)	≥ 30%
Hardness (HRB)	≤ 95

Types of Forged Couplings

Full Coupling – Connects two pipes of equal diameter.
Half Coupling – Used for connecting pipe to fittings or valves.
Reducing Coupling – Joins pipes of different sizes.
Socket Weld Coupling – For strong, permanent welded connections.
Threaded Coupling – Allows quick assembly/disassembly in threaded lines.

Applications of Forged Couplings

Oil & Gas Industry – Inline joints in pressurized pipelines.
Chemical Plants – Connecting corrosive fluid systems.
Power Generation – Piping in high-pressure steam and water lines.
Marine Systems – Corrosion-resistant pipe connectors.
General Industries – Versatile connections for air, gas, and water systems.

Benefits of Forged Couplings

Strong and reliable inline pipe connection
Long service life under pressure and temperature extremes
Easy to install with socket weld or threaded ends
Available in reducing, full, and half versions
Precision machining for leak-proof joints

Frequently Asked Questions

Explore our FAQs for insights on materials, customization, and delivery.

What is the purpose of a forged coupling?

To join two sections of pipe in-line, maintaining strength and pressure integrity.

Are reducing couplings available?

Yes, we supply standard and custom reducing couplings.

Which is better: socket weld or threaded?

Socket weld is ideal for permanent, high-pressure systems; threaded is best for quick installation and maintenance.

Can you supply custom sizes or alloys?

Yes, we offer custom sizing, threading, and materials based on your project needs.
