Stainless Steel
Hexagonal Bars Manufacturer
At Steel Icon Stainless Pvt. Ltd., we are a leading manufacturer and exporter of stainless steel hexagonal bars in India. Our hex bars are engineered with precision and consistency to meet global quality standards, including ASTM, ASME, DIN, and EN. Available in a wide range of sizes, grades, and finishes, our hex bars are designed to perform in diverse industrial applications, offering high strength, machinability, and corrosion resistance.
What are Stainless Steel Hexagonal Bars?
Stainless steel hexagonal bars are six-sided metal bars used in precision machining, fabrication, and component manufacturing. With their uniform shape and strength, they are ideal for use in fasteners, shafts, tools, and automotive parts. Their easy machinability and excellent resistance to corrosion and wear make them suitable for both aesthetic and functional applications.
| Products |
|---|
|
Stainless Steel Bar |
|
Fasteners |
|
Forged Products |
|
Flanges |
|
Forged Fittings |
|
Stainless Steel Billets |
|
Round Corner Square Billets |
|
Stainless Steel Pipes |
|
Pipe Fittings |
|
Valve |
Stainless Steel Hexagonal Bars Specifications
| Property | Specification |
|---|---|
|
Material Grades |
SS 304, SS 316, SS 321, SS 410, SS 430 |
|
Across Flats (AF) |
6mm – 100mm |
|
Thickness |
2mm – 50mm |
|
Length |
Up to 6 meters (Custom sizes available) |
|
Surface Finish |
Bright, Black, Polished, Peeled & Ground |
|
Manufacturing Process |
Hot Rolled, Cold Drawn, Centreless Ground |
|
Standard & Compliance |
ASTM A276, ASME SA479, EN 10088, DIN 1.4301 |
Grades of Stainless Steel Hexagonal Bars
Stainless Steel Hexagonal Bars Equivalent Grades
| Grade | UNS | EN / WNR |
|---|---|---|
|
SS 304 |
S30400 |
1.4301 / X5CrNi18-10 |
|
SS 316 |
S31600 |
1.4401 / X5CrNiMo17-12-2 |
|
SS 321 |
S32100 |
1.4541 / X6CrNiTi18-10 |
|
SS 410 |
S41000 |
1.4006 / X12Cr13 |
|
SS 430 |
S43000 |
1.4016 / X6Cr17 |
Stainless Steel Hexagonal Bars Chemical Composition
| Element | SS 304 (%) | SS 316 (%) | SS 321 (%) |
|---|---|---|---|
|
Carbon (C) |
0.08 max |
0.08 max |
0.08 max |
|
Manganese (Mn) |
2.00 max |
2.00 max |
2.00 max |
|
Silicon (Si) |
1.00 max |
1.00 max |
1.00 max |
|
Chromium (Cr) |
18.0 – 20.0 |
16.0 – 18.0 |
17.0 – 19.0 |
|
Nickel (Ni) |
8.0 – 10.5 |
10.0 – 14.0 |
9.0 – 12.0 |
|
Molybdenum (Mo) |
— |
2.00 – 3.00 |
— |
Stainless Steel Hexagonal Bars Mechanical Properties
| Property | SS 304 | SS 316 | SS 321 |
|---|---|---|---|
|
Tensile Strength (MPa) |
515 – 650 |
515 – 650 |
515 – 650 |
|
Yield Strength (MPa) |
205 min |
205 min |
205 min |
|
Elongation (%) |
40 min |
40 min |
40 min |
|
Hardness (HRB) |
80 max |
80 max |
80 max |
Applications of Stainless Steel Hexagonal Bars
Construction &
Infrastructure
Marine &
Offshore
Automotive &
Transportation
Manufacturing &
Heavy Equipment
Chemical &
Pharmaceutical Plants
Oil & Gas
Food & Beverage
Industry
Explore Our Types of Stainless Steel Bars
We also offer specialised stainless steel bars tailored for specific applications
