Welded Pipes Manufacturer
At Steel Icon Stainless Pvt. Ltd., we manufacture and supply high-quality welded pipes engineered for strength, corrosion resistance, and long service life in both high-pressure and low-pressure environments. Our welded pipes are available in ERW (Electric Resistance Welded), EFW (Electric Fusion Welded), and SAW (Submerged Arc Welded) formats, crafted using premium stainless steel, carbon steel, alloy steel, and duplex materials.
Our facilities are equipped to produce welded pipes that meet stringent international standards such as ASTM, ASME, DIN, EN, and ISO, suitable for diverse industries like oil & gas, construction, HVAC, chemical processing, food & beverage, water distribution, and marine engineering.
What Are Welded Pipes?
Welded pipes are manufactured by rolling and welding steel plates or coils into cylindrical shapes. The weld seam can be longitudinal or spiral, depending on the process. These pipes are commonly used in applications that require large diameters, cost-effectiveness, and high mechanical strength.
Welded pipes are available in a variety of types such as ERW, EFW, SAW, and LSAW, depending on the welding process and pressure rating.
| Products |
|---|
|
Stainless Steel Bar |
|
Fasteners |
|
Forged Products |
|
Flanges |
|
Forged Fittings |
|
Stainless Steel Billets |
|
Round Corner Square Billets |
|
Stainless Steel Pipes |
|
Pipe Fittings |
|
Valve |
Product Specifications
| Property | Specification |
|---|---|
|
Material Grades |
SS 304, 316, 321, 310, Duplex 2205/2507, CS, MS, Alloy Steel
|
|
Size Range |
1/2” NB to 72” NB |
|
Wall Thickness |
SCH 5 to SCH 160 / XXS |
|
Length |
Single Random, Double Random, Cut Lengths |
|
Form |
Round, Square, Rectangular |
|
Weld Types |
ERW, EFW, SAW, LSAW |
|
Standards |
ASTM A312, ASTM A358, ASTM A671, ASME B36.10/B36.19, EN 10217, ISO 3183 |
Types of Welded Pipes
- ERW (Electric Resistance Welded) Pipes – Suitable for medium-pressure applications
- EFW (Electric Fusion Welded) Pipes – Used for high-temperature services
- SAW (Submerged Arc Welded) Pipes – Ideal for large-diameter and high-strength piping
- LSAW (Longitudinal Submerged Arc Welded) – Preferred in structural and pipeline systems
Available Grades
- Stainless Steel: 304, 304L, 316, 316L, 321, 310
- Duplex Steel: UNS S31803, S32205, S32750, S32760
- Carbon Steel: A53, A106, API 5L Gr B, ASTM A671
- Alloy Steel: P11, P22, P91, WP5, WP9
Chemical Composition (Typical for SS 304 / SS 316)
| Element | SS 304 (%) | SS 316 (%) |
|---|---|---|
|
Carbon (C) |
0.08 max |
0.08 max |
|
Chromium (Cr) |
18.0 – 20.0 |
16.0 – 18.0 |
|
Nickel (Ni) |
8.0 – 10.5 |
10.0 – 14.0 |
|
Molybdenum (Mo) |
— |
2.00 – 3.00 |
Mechanical Properties
| Property | SS 304 / SS 316 |
|---|---|
|
Tensile Strength |
515–750 MPa |
|
Yield Strength |
205–310 MPa |
|
Elongation (%) |
≥ 30% |
|
Hardness (HRB) |
≤ 95 |
Applications of Stainless Steel Pipes
Construction &
Infrastructure
Marine &
Offshore
Automotive &
Transportation
Manufacturing &
Heavy Equipment
Chemical &
Pharmaceutical Plants
Oil & Gas
Food & Beverage
Industry
Benefits of Welded Pipes
- Cost-effective compared to seamless pipes
- Available in larger diameters
- Quick production turnaround
- Excellent weld integrity and pressure ratings
- Customizable lengths and wall thicknesses
Frequently Asked Questions
Standard orders ship within 3-7 days, while custom orders take 7-14 days, depending on requirements.
